| Model | AD-CA128SATA200AR | |||
|---|---|---|---|---|
| Flash Type | 1.8" SATA to CFast Card Adapter | |||
| SATA / CFast™ specification | Compliant with Serial ATA 1.0a & 2.6 & 3.0 specification Compliant with CFast™ specification Ver2.0 1.8" form-factor with 4 standard 1.8" HDD | |||
| Host interface | SATA 7-pin (data) + 15-pin (5V power connector) | |||
| CFast™ Socket | SATA 7-pin (data) + 17-pin (3.3V power connector) Socket x 1 | |||
| Data Transfer Mode | Serial ATA Gen-I/Gen-II/Gen-III (1.5Gb/s,3.0Gb/s and 6.0Gb/s) | |||
| Bootable | Yes | |||
| Operation Voltage | +5V | |||
| Operating Temperature | 0°C~+70°C | |||
| Non-operating Temperature | -20°C~+80°C | |||
| Relative Humidity | Max 90% | |||
| Supported O.S. | Compatible with DOS, Windows / Linux and O.S. | |||
| Dimension (WxLxH,mm) | 68.58 x 60.00 x 8.00 |
