Industrial PCIe Gen4x4, NVMe

Silicon Power

  • Compliant with NVMe Express 1.3
  • Supports Data Security AES Encryption (optional)
  • Supports SP Toolbox Smart Health Monitoring System software
Model MED350S
Flash Technology 3D TLC
Interface PCIe Gen4x4, NVMe
Capacity 128GB ~ 2TB
Seq. Performance Read (max.) 3.500 MB/s (estimated)
Seq. Performance Write (max.) 3.000 MB/s (estimated)
Random 4K Read (IOPS max.) 350.000 (estimated)
Random 4K Write (IOPS max.) 350.000 (estimated)
Power Requirement DC 3.3V
Power Consumption (max.) -
Power Consumption (idle) -
Dimension (mm) 110.0 x 22.0 x 3.6
MTBF ≒2,000,000 hrs
Temperature
Operating 0°C ~ 70°C: Standard SP***GIMED35*SV0
Operating -15°C ~85°C: Extended SP***GIMED35*SE0
Operating -40°C ~ 85°C: Wide SP***GIMED35*SW0
Key Features
Power Shield
Power Fail Protection
End-to-End Data Protection
TRIM
S.M.A.R.T
DEVSLP
Advanced Encryption Standard 256
SP SMART Utility
