| Model | MEA3K0E | |||
|---|---|---|---|---|
| Flash Technology | 3D TLC | |||
| Interface | PCIe Gen3x2, NVMe 1.4 | |||
| Capacity | 64GB~1TB | |||
| Seq. Performance Read (max.) | 1,785 MB/s | |||
| Seq. Performance Write (max.) | 1,780 MB/s | |||
| Random 4K Read (IOPS max.) | 251,000 | |||
| Random 4K Write (IOPS max.) | 281,000 | |||
| Power Requirement | DC 3.3V | |||
| Power Consumption (max.) | 880 mA | |||
| Power Consumption (idle) | 307 mA | |||
| Dimension (mm) | 42.0 x 22.0 x 3.5 mm | |||
| MTBF | ≒3,000,000 hrs | |||
| Temperature | ||||
| Operating 0°C ～ 70°C: Standard | - | |||
| Operating -20°C ～75°C: Extended | SP***GIMEA3K5EVB | |||
| Operating -40°C ～ 85°C: Wide | SP***GIMEA3K5EWB | |||
| Key Features | ||||
| Power Shield | ● | |||
| Power Fail Protection | ||||
| End-to-End Data Protection | ● | |||
| TRIM | ● | |||
| S.M.A.R.T | ● | |||
| DEVSLP | ● | |||
| Advanced Encryption Standard 256 | ● | |||
| SP SMART Utility | ● | |||
